CR-615P Card collector Technical Information
Elementary functional Introduction
Card material: All kinds of paper cards and PVC/ Mylar cards;
Net of card collector: About 0.7kg;
Collect time: About 2S;
Electrical Specifications
Environmental Specification
Control interface description
TTL electrical level control interface is offered by the DCR-615 card collector which is educed by the CN1 of electrical outlet in the control broad. The socket connectors with 2.54 mm space between is used as electrical outlet.
Interface description
Code of pin
Signal name
Signal description
1
GND(0 V)
power
2
+24V(DC)
3
GND
0V
4
Receive
Low voltage is effective(the last time exceed 200ms)
5
Reject
DescriptLow voltage is effective(the last time exceed200ms)ion
6
NC
non use
7
Enable
10K upward pull input,Low voltage is effective
8
NC
non use
9
Received
Output open collector,Low voltage is effective(about500ms)
10
Get Card
Output open collector, Low voltage is effective
11
Rejected
Output open collector Low voltage is effective
12
Jammed
Output open collector Low voltage is effective
Control signal description
Receive: the signal of receive is input when Getcard output is effective signal (low voltage). The card is collected into the warehouse(with high voltage in the collecting procession)。The signal can be trade as the input signal of card collecting in force under jamming;
Reject: When GetCard output is effective(low voltage)the reject signal is input,card is quitted (GetCard is high voltage within the quitting procession )。The signal can be trade as the input signal of card quitting in force under jamming;
Enable: The card collector is permitted to work under low voltage。The card collector is prohibited under high voltage。The signal of enable can be used as the input of vehicles detector;
Received: The low voltages signal will be input with the width of 200ms .It can spring the opening of the road barrier after the card being received to the box;
GetCard: The pin will input the low voltage when card entry from the entrance of the card collector.The low voltage will last until the monitor computer sends the receiving/quitting signal or card quitted as to overtime.
Quitting card if overtime:the card will be quitted automatically and the rejected signal will be input after the waiting time exceed T1.The range of T1 is determined by the DIP1 and DIP2 of the switch S1:
DIP1
OFF
OFF
ON
ON
DIP2
OFF
ON
OFF
ON
Time
rejection
3S
10S
30S
Rejected: The pin will input the low voltage signal (lasting about 200ms at least) until the cad is took away or took back after the card quitted to the entrance;
Jammed: Card-jammed or the card is in the reading place waiting for the signal of receiving/quitting;
Card-quitting automatically
Time of card quitting automatically
Indication of the work condition
