Features:
1. Front 3mm bezel aluminum alloy brushed metal craft, seamless design, front IP65 waterproof and dustproof.
2. Industrial LCD panel, wide viewing angle, high nits, true color.
3. Adopt multi-points PCAP touch panel, high sensitive and fast-response. Covered with 2mm tempered glass for vandalproof.
4. 1000 nits, sunlight readable
5. Anti glare. Optical Bonding
6. High performance mainboard, 7x24 continuous operation.
7. Wide temperature range: operating: -20 to 70C, storage: -30 to 85*C.
8. Support wall mounting, embedded mounting, desk stand mounting etc.
LCD Panel
Panel size
17
Resolution
4:3
Aspect Color
16.7M colors
Brightness(cd/m2)
1000nits,sunlight readable
Contrast ratio
1000:1
View angle
85° / 85° / 85° /85° (R/L/U/D)
Touch Panel
Touchscreen Type
Project Capacitive Touch (10 points)
Surface Treatment
Anti Glare
Surface Hardness
7H
Luminousness
90%
Touch Interface
USB (RS232 optional)
Touch response time
2ms
Working Life
>50 million times
Touch option
(5 wires restive touch,IR touch, Without touch Optional)
Signal Ports
Description
VGA
Description
HDMI
Description
DVI
Description
Audio in/out
Description
Signal Ports
VGA
1xVGA
HDMI
1xHDMI
DVI
1xDVI
Audio in/out
optional
